cimpy.cgmes_v2_4_15.ConformLoadSchedule module¶
-
class
cimpy.cgmes_v2_4_15.ConformLoadSchedule.
ConformLoadSchedule
(ConformLoadGroup=None, *args, **kw_args)[source]¶ A curve of load versus time (X-axis) showing the active power values (Y1-axis) and reactive power (Y2-axis) for each unit of the period covered. This curve represents a typical pattern of load over the time period for a given day type and season.
- ConformLoadGroup
The ConformLoadGroup where the ConformLoadSchedule belongs. Default: None
Documentation of parent class SeasonDayTypeSchedule:
A time schedule covering a 24 hour period, with curve data for a specific type of season and day.
- DayType
Schedules that use this DayType. Default: None
- Season
Schedules that use this Season. Default: None
Documentation of parent class RegularIntervalSchedule:
The schedule has time points where the time between them is constant.
- timeStep
The time between each pair of subsequent regular time points in sequence order. Default: 0
- endTime
The time for the last time point. Default: ‘’
- TimePoints
The regular interval time point data values that define this schedule. Default: “list”
Documentation of parent class BasicIntervalSchedule:
Schedule of values at points in time.
- startTime
The time for the first time point. Default: ‘’
- value1Unit
Value1 units of measure. Default: None
- value2Unit
Value2 units of measure. Default: None
Documentation of parent class IdentifiedObject:
This is a root class to provide common identification for all classes needing identification and naming attributes.
- DiagramObjects
The domain object to which this diagram object is associated. Default: “list”
- mRID
Master resource identifier issued by a model authority. The mRID is globally unique within an exchange context. Global uniqueness is easily achieved by using a UUID, as specified in RFC 4122, for the mRID. The use of UUID is strongly recommended. For CIMXML data files in RDF syntax conforming to IEC 61970-552 Edition 1, the mRID is mapped to rdf:ID or rdf:about attributes that identify CIM object elements. Default: ‘’
- name
The name is any free human readable and possibly non unique text naming the object. Default: ‘’
- description
The description is a free human readable text describing or naming the object. It may be non unique and may not correlate to a naming hierarchy. Default: ‘’
- energyIdentCodeEic
The attribute is used for an exchange of the EIC code (Energy identification Code). The length of the string is 16 characters as defined by the EIC code. References: Default: ‘’
- shortName
The attribute is used for an exchange of a human readable short name with length of the string 12 characters maximum. Default: ‘’
-
cgmesProfile
¶ alias of
cimpy.cgmes_v2_4_15.Base.Profile
